设备产能

Equipment capacity

5000支/小时（受工艺影响）

5000 pcs/h (affected by the technique)

整机功率

Overall power

0.6kw  220v 50HZ

加液枪头数量

Number of liquid filling gun

2支（可依需求选择）

2(select as required)

试管规格

Test tube specification

Ø8管 Ø13管（13*100 13*75管通用）或Ø16管（Ø8管 Ø13管 Ø16管夹具不通用）

Tube Ø8 Ø13 (universal for 13*100  13*75 tube), or Ø16 tube (non-universal for Ø8 tube, Ø13 tube and Ø16 tube fixtures)

耗气量

Gas consumption

≤0.2m³/min，气源压力：0.5Mpa≤p≤0.8Mpa

≤0.2m³/min, air source pressure: 0.5Mpa≤p≤0.8Mpa

整机外形尺寸

Overall boundary dimension

长1750mm*宽850mm*高1830mm

Length 1750mm* width 850mm* height 1830mm

整机重量

Overall weight

约80kg

Approx. 80kg
